CK series CNC milling machine is a universal processing machine with excellent performance, safety and durability. The functional structure adopts modern design theory and ergonomic design, simple operation, excellent reliability and pleasantness.
This series of machine tools is suitable for the needs of the defense industry, aerospace, petrochemical, automotive, railway, ship and other fields. It can realize the inner and outer surfaces of the shaft and disc, the conical surface, the circular arc surface, various common thread, boring and reaming, and can also realize non-circular curve processing. The machine tool has high processing efficiency, good precision retention, and high interchangeability of processed products.
The series of machine tools adopts the overall horizontal flat bed and adopts the combination of double triangular guide rails. The machine guide rails are treated by super-audio quenching, which has high hardness and wear resistance.
| project | unit | Ck6156 |
| Maximum turning diameter of the bed | mm | Ф560 |
| Rail span | mm | 435 |
| Maximum workpiece length | mm | 750 1100 1500 2000 |
| Cutting length | mm | 700 1050 1450 1950 |
| Cutting diameter | mm | 560 (立四) 420 (立六) |
| Maximum turning diameter on the skateboard | mm | 300 |
| Cutting diameter | mm | 460 |
| Maximum turning diameter on the skateboard | mm | 280 |
| Spindle end type and code | mm | A8 |
| Taper taper in front of the spindle | 1:20 | |
| Spindle aperture | mm | 80 |
| Spindle speed series | n | No step in manual third gear |
| Spindle speed range | r/min | 36-366 78-785 178-1600 |
| main motor power | kw | 7.5/11 |
| Maximum load bearing (disc type) / (shaft type) | kg | 700/1400 |
